| Place of Origin: | Shandong, China |
| Brand Name: | Classic |
| Model Number: | vmc640 |
| Price: | $12,000.00/Sets 1-4 Sets |
|---|---|
| Packaging Details: | The machine will be packed by the playwood case<br>Hot selling cheap custom popular product cnc machine milling for sale |
| Supply Ability: | 50 Set/Sets per Month |
| Type: | VERTICAL | Range Of Spindle Speed(r.p.m): | 60 - 8000 |
|---|---|---|---|
| Number Of Axes: | 4 | No. Of Spindles: | Single |
| Machining Capacity: | Light Duty | Spindle Taper: | BT30/BT40 |
| Table Travel (X) (mm): | 600 Mm | Table Travel (Y) (mm): | 400 Mm |
| Table Travel (Z) (mm): | 500 Mm | Positioning Accuracy (mm): | 0.01 |
| Repeatability (X/Y/Z) (mm): | 0.005 | Condition: | New |
| Table Travel (mm): | 800*320 | Year: | 2021 |
| Voltage: | 380V | Dimension(L*W*H): | 1900*1800*2100 |
| CNC Control System: | KND | Key Selling Points: | Competitive Price |
| Weight (KG): | 2500 | Spindle Motor Power(kW): | 5.5 |
| Warranty: | 2 Year | Max. Table Load(kg): | 300 Kg |
| Applicable Industries: | Manufacturing Plant | Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, R |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 2 Years |
| Core Components: | Bearing | CNC Or Not: | CNC |
| T Slot Qty-width*distance: | 3-14x110 | Spindle Speed: | 60-8000 R P M |
| Spindle Nose To Table Surface: | 125-520mm | Spindle Center To Column Surface: | 360 |
| Main Motor Power: | 3.7kw (servo) | Machine Type: | Cnc Vertical Milling Machine |
| Application: | Metal Machining | Color: | Custom-made |
| Product Name: | Vertical Machininig Center | Port: | Qingdao Or Shanghai Port |
specifications | unit | VMC640 |
Table size | mm | 800x320 |
X axis travel | mm | 600 |
Y axis travel | mm | 300 |
Z axis travel | mm | 400 |
Distance between spindle center and column surface | mm | 469 |
Distance between spindle nose and table surface | mm | 100-600 |
T slot | 3-18*125 | |
Spindle taper | mm | BT40 |
Max. spindle speed | r/min | 8000(10000 optional) |
Main motor power | kw | 5.5 |
X/Y/Z axis servo motor torque | N.M | 10/10/15 |
X/Y/Z motor connection | direct | |
X/Y/Z guide rail form | 3 axis linear guide rail | |
Max.table load | kg | 450 |
Automatic tools changer | 16 Armless type(optional:24 arm type) | |
Max.tool weight | kg | 7 |
Max. tool length | mm | 250/350 |
Max. tool diameter | mm | 100(Adjacent)/150(Apart) |
X/Y/Z axis rapid traverse | M/min | 24(optional :48) |
Cutting feed speed | M/min | 10 |
Position accuracy | mm | ±0.005 |
Repeat positioning accuracy | mm | ±0.003 |
Machine dimension | mm | 1710*2100*2250 |
Machine weight | kg | 3000 |
