| Place of Origin: | Shandong, China |
| Brand Name: | Classic |
| Model Number: | XH7126 |
| Price: | $14,000.00/Sets 1-4 Sets |
|---|---|
| Packaging Details: | The machine will be packed by the playwood case<br>Hot selling cheap custom popular product cnc machine milling for sale |
| Supply Ability: | 50 Set/Sets per Month |
| Type: | VERTICAL | Range Of Spindle Speed(r.p.m): | 1 - 6000 |
|---|---|---|---|
| Number Of Axes: | 4 | No. Of Spindles: | Single |
| Machining Capacity: | Light Duty | Spindle Taper: | BT30/BT40 |
| Table Travel (X) (mm): | 450 | Table Travel (Y) (mm): | 320 |
| Table Travel (Z) (mm): | 420 | Positioning Accuracy (mm): | 0.01 |
| Repeatability (X/Y/Z) (mm): | 0.005 | Condition: | New |
| Table Travel (mm): | 800*260 | Year: | 2021 |
| Voltage: | 380V | Dimension(L*W*H): | 2600*1950*2400 |
| CNC Control System: | KND | Key Selling Points: | Competitive Price |
| Weight (KG): | 2400 | Spindle Motor Power(kW): | 3.7 |
| Warranty: | 2 Year | Max. Table Load(kg): | 500 Kg |
| Applicable Industries: | Manufacturing Plant | Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, R |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 2 Years |
| Core Components: | Bearing | CNC Or Not: | CNC |
| T Slot Qty-width*distance: | 3-14x110 | Spindle Speed: | 60-8000 R P M |
| Spindle Nose To Table Surface: | 125-520mm | Spindle Center To Column Surface: | 360 |
| Main Motor Power: | 3.7kw (servo) | Machine Type: | Cnc Vertical Milling Machine |
| Application: | Metal Machining | Color: | Custom-made |
| Product Name: | Vertical Machininig Center | Port: | Qingdao Or Shanghai Port |
|
Specificiton
|
XH7126
|
|
Worktable size (LXW)
|
800X260mm
|
|
T-slot (NXWXD)
|
3/14/80mm
|
|
X axis travel
|
450mm
|
|
Y axis travel
|
320mm
|
|
Z axis travel
|
450mm
|
|
Distance from spindle nose to worktable surface
|
90-470mm
|
|
Distance from spindle center to column
|
360mm
|
|
Rapid feed speed (X/Y/Z)
|
15/15/15 m/min.
|
|
Spindle taper
|
BT40
|
|
Spindle speed
|
6000rpm or 8000rpm
|
|
Main motor power
|
3.7Kw
|
|
Servo motor torque (X/Y/Z)
|
6/6/7.7 N.m
|
|
Overall size (LXWXH)
|
2100X1800X1960mm
|
|
Net weight
|
2400kg
|
|
Net Weight
|
2500kg
|
|
Overall Dimension
|
1900x1800x2100
|
