| Place of Origin: | Shandong, China |
| Brand Name: | Classic |
| Price: | $26,000.00/Sets 1-1 Sets |
|---|---|
| Packaging Details: | The machine will be packed by the plywood case<br>Hot-selling CNC horizontal milling machining center HMC630 for metal machining |
| Supply Ability: | 500 Set/Sets per Year |
| Condition: | New | Spindle Taper: | BT40 |
|---|---|---|---|
| No. Of Spindles: | 1 | Type: | Horizontal |
| Dimension(L*W*H): | 3000*2450*2650mm | Weight (T): | 6.5 T |
| Table Size (mm): | 800*500 | CNC Control System: | GSK, KND, Siemens |
| Number Of Axes: | 4 | Table Travel (X) (mm): | 1000 Mm |
| Table Travel (Y) (mm): | 800 Mm | Table Travel (Z) (mm): | 800 Mm |
| Positioning Accuracy (mm): | 0.01 Mm | Repeatability (X/Y/Z) (mm): | 0.002mm |
| Range Of Spindle Speed(r.p.m): | 60 - 8000 R.p.m | Spindle Motor Power(kW): | 11/15 |
| Max. Table Load(kg): | 1200 Kg | Feed Speed(mm/min): | 10 - 10000 Mm/min |
| Rapid Feed Speed(m/min): | 15/15/15 | Min. Time Of Tool Change(s): | 2 |
| Tool Magazine Capacity: | 24 | Key Selling Points: | Multifunctional |
| Warranty: | 2 Year | Voltage: | 220V/380V/480V |
| Applicable Industries: | Machinery Repair Shops | Showroom Location: | Egypt, Italy, France, Germany, Viet Nam, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Bangladesh, South Africa, Ukraine, Kyrgyzstan |
| Marketing Type: | New Product 2022 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 2 Years |
| Core Components: | Motor | T Slot: | 8-18*90mm |
| Spindle Nose To Table Surface: | 50-500mm | Spindle Center To Table: | 0-650mm |
| Machine Type: | CNC Machining Center | Application: | General Machinery Processing |
| Controlling Mode: | Fanuc Mitsubishi Siemens Gsk System | Product Type: | Cnc 3/4/5 Axis Machine |
| Processing: | Metal Cutting Cnc Milling Machine | Precision: | Precision |
| Function: | Machining Metal | Port: | Qingdao Or Shanghai Port |
|
HMC630(double positions)
|
|
|
|
|
||||
|
|
Item
|
|
unit
|
|
||||
|
Table
|
table size
|
|
mm
|
630x630
|
||||
|
|
table numubers
|
|
pc
|
2
|
||||
|
|
Max.load of table
|
|
kg
|
1200
|
||||
|
|
T slot
|
|
|
5-18-125
|
||||
|
|
talbe indexing
|
|
|
1°
|
||||
|
|
table Max. speed
|
|
rpm
|
16.7
|
||||
|
Machining arrange
|
table travel(left/right) X
|
|
mm
|
1000
|
||||
|
|
Headstock travel(up/down) Y
|
|
mm
|
800
|
||||
|
|
table travel(Front/back) Z
|
|
mm
|
800
|
||||
|
|
Max. workpiece Dia.
|
|
mm
|
Φ1000×900
|
||||
|
|
distance from spindle axis to table surface
|
|
mm
|
50-850
|
||||
|
|
distance from table center to spindle nose
|
|
mm
|
200-1000
|
||||
|
spindle
|
spindel taper
|
|
|
BT50
|
||||
|
|
spindle speed
|
|
rpm
|
3000
|
||||
|
|
Max.spindle torque
|
|
N.M
|
770(ZF BOX)
|
||||
|
|
main motor power
|
|
KW
|
15/18.5
|
||||
|
|
Max.drilling Dia.
|
|
mm
|
50
|
||||
|
|
Max. tapping Dia.(casting)
|
|
mm
|
M30
|
||||
|
|
Max. tapping Dia.(stell)
|
|
mm
|
M24
|
||||
|
feed
|
cutting feed
|
|
m/min
|
1-12
|
||||
|
|
rapid speed
|
|
m/min
|
24
|
||||
|
ATC
|
standard arm type
|
|
nos
|
24
|
||||
|
|
Max. tool Dia.
|
|
mm
|
110
|
||||
|
|
Max. empty tool Dia.
|
|
mm
|
220
|
||||
|
|
Max.tool length
|
|
mm
|
400
|
||||
|
|
Max. tool weight
|
|
Kg
|
25
|
||||
|
Accuracy
|
Positioning accuracy
|
x,y,z axis
|
mm
|
0.01
|
||||
|
|
|
B axis
|
Arc sec
|
10
|
||||
|
|
Repeat positioning accuracy
|
x,y,z axis
|
mm
|
0.005
|
||||
|
|
|
B axis
|
Arc sec
|
2
|
||||
|
Air supply
|
|
|
Mpa
|
0.5-0.7
|
||||
|
Machine overal dimensions
|
|
|
mm
|
5600×3300×3100
|
||||
|
|
|
|
|
(L*W*H)
|
||||
|
Machine weight
|
|
|
kg
|
18000
|
||||
