| Place of Origin: | Shandong, China |
| Brand Name: | Classiccnc |
| Model Number: | XH7125 |
| Price: | $11,999.00/Sets 1-2 Sets |
|---|---|
| Packaging Details: | The machine will be packed by the plywood case<br>Mini universal metal CNC milling machine XH7125 china CNC milling machine |
| Supply Ability: | 50 Set/Sets per Month |
| Type: | VERTICAL | Range Of Spindle Speed(r.p.m): | 1 - 6000 |
|---|---|---|---|
| Number Of Axes: | 3 | No. Of Spindles: | Single |
| Machining Capacity: | Medium Duty | Spindle Taper: | BT40/BT30 |
| Table Travel (X) (mm): | 450 | Table Travel (Y) (mm): | 260 |
| Table Travel (Z) (mm): | 380 | Positioning Accuracy (mm): | ±0.01 |
| Repeatability (X/Y/Z) (mm): | ±0.02 | Condition: | New |
| Table Travel (mm): | 900x250 | Year: | 2022 |
| Voltage: | 380/240V | Dimension(L*W*H): | 2200*1650*2200mm |
| CNC Control System: | GSK/fanuc/KND/Siemens | Key Selling Points: | Automatic |
| Weight (KG): | 1800 | Spindle Motor Power(kW): | 2.2 |
| Warranty: | 2 Years | Max. Table Load(kg): | 300 Kg |
| Applicable Industries: | Garment Shops, Manufacturing Plant, Machinery Repair Shops, Construction Works , Other | Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Alge |
| Marketing Type: | New Product 2022 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 24 Months |
| Core Components: | Bearing, Motor, Gear, Engine | Product Name: | Milling Machine Center Frame |
| Machine Type: | Machining Center | Application: | Metal Processing |
| Function: | Vertical Milling Machining | Name: | 3 Axis Milling Machine |
| Keyword: | Cnc 3 Axis Milling Machine | Precision: | High Precision |
| Product Type: | Cnc 3/4/5 Axis Machine | Usage: | Processing Machine |
| CNC Or Not: | CNC Machining Center | Port: | Qingdao Or Shanghai Port |
|
Specifications
|
Unit
|
XH7125
|
|
Table size
|
mm
|
900×250
|
|
X-axis travel
|
mm
|
450
|
|
Y-axis travel
|
mm
|
260
|
|
Z-axis travel
|
mm
|
380
|
|
Distance from spindle axis to column surface
|
mm
|
330
|
|
Distance between spindle nose and worktable
|
mm
|
50-430
|
|
The vertical tolerance of distance between spindle nose and worktable
|
mm
|
≦0.02
|
|
X/Y/Z rapid traverse
|
M/min
|
6/5/4
|
|
Max.spindle speed
|
rpm
|
6000
|
|
Spindle taper
|
|
BT30
|
|
Main motor power
|
kw
|
2.2
|
|
X axis motor torque
|
N.m
|
7.7
|
|
Y axis motor torque
|
N.m
|
6
|
|
Z axis motor torque
|
N.m
|
6
|
|
Tool capacity
|
|
12 armless type tools magazine
|
|
Positioning accuracy
|
mm
|
0.02
|
|
Repeat positioning accuracy
|
mm
|
0.01
|
|
Machine dimension
|
mm
|
2200×1650×2200
|
|
Machine weight
|
kg
|
1800
|
