| Place of Origin: | Shandong, China |
| Brand Name: | Classiccnc |
| Model Number: | XK7126 |
| Price: | $15,000.00/Sets 1-2 Sets |
|---|---|
| Packaging Details: | The machine will be packed by the plywood case<br>Small machining center VMC650 China 3/4/5 axis small vertical CNC machining center |
| Supply Ability: | 50 Set/Sets per Month |
| Type: | VERTICAL | Range Of Spindle Speed(r.p.m): | 60 - 8000 |
|---|---|---|---|
| Number Of Axes: | 3 | No. Of Spindles: | Single |
| Machining Capacity: | Heavy Duty | Spindle Taper: | BT40 |
| Table Travel (X) (mm): | 450 | Table Travel (Y) (mm): | 260 |
| Table Travel (Z) (mm): | 380 | Positioning Accuracy (mm): | 0.001 |
| Repeatability (X/Y/Z) (mm): | 0.004 | Condition: | New |
| Table Travel (mm): | 900*250 | Year: | 2021 |
| Voltage: | 380/240V | Dimension(L*W*H): | 2600*1950*2400mm |
| CNC Control System: | GSK/fanuc/KND/Siemens | Key Selling Points: | Automatic |
| Weight (KG): | 2400 | Spindle Motor Power(kW): | 5.5 |
| Warranty: | 2 Years | Max. Table Load(kg): | 200 Kg |
| Applicable Industries: | Hotels, Garment Shops, Manufacturing Plant, Machinery Repair Shops, Construction Works , Other | Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Alge |
| Marketing Type: | New Product 2022 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 2 Years |
| Core Components: | Bearing | Product Name: | Milling Machine Center Frame |
| Machine Type: | Machining Center | Application: | Metal Processing |
| Function: | Vertical Milling Machining | Name: | 3 Axis Milling Machine |
| Keyword: | Cnc 3 Axis Milling Machine | Precision: | High Precision |
| Product Type: | Cnc 3/4/5 Axis Machine | Usage: | Processing Machine |
| CNC Or Not: | CNC Machining Center | Port: | Qingdao Or Shanghai Port |
|
Specificiton
|
XK7126
|
|
Worktable size (LXW)
|
800X260mm
|
|
T-slot (NXWXD)
|
3/14/80mm
|
|
X axis travel
|
450mm
|
|
Y axis travel
|
320mm
|
|
Z axis travel
|
450mm
|
|
Distance from spindle nose to worktable surface
|
90-470mm
|
|
Distance from spindle center to column
|
360mm
|
|
Rapid feed speed (X/Y/Z)
|
15/15/15 m/min.
|
|
Spindle taper
|
BT40
|
|
Spindle speed
|
6000rpm or 8000rpm
|
|
Main motor power
|
3.7Kw
|
|
Servo motor torque (X/Y/Z)
|
6/6/7.7 N.m
|
|
Overall size (LXWXH)
|
2100X1800X1960mm
|
|
Net weight
|
2400kg
|
