Hot selling good quality popular product radial drilling machine with radial arm

Product Details:

Place of Origin:	Shandong, China
Brand Name:	Classic

Payment & Shipping Terms:

Price:	$7,300.00/Pieces 1-4 Pieces
Packaging Details:	The machine will be packed by the plywood case<br>Hot selling good quality popular product radial drilling machine with radial arm
Supply Ability:	500 Set/Sets per Year

Contact Now

Detailed Product Description

Condition:	New	Type:	Radial Drilling Machine
Max. Drilling Dia. (mm):	50mm	Range Of Spindle Speed(r.p.m):	25 - 2000 R.p.m
CNC Or Not:	Normal	Drilling Speed:	25-2500
Voltage:	220V/380V	Dimension(LWH):	270011202500
Power (kW):	5.5	Weight (KG):	3500 KG
Warranty:	2 Years	Key Selling Points:	Multifunctional
Showroom Location:	Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Alge	Applicable Industries:	Manufacturing Plant, Machinery Repair Shops, Retail
Marketing Type:	New Product 2022	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	2 Years
Core Components:	Bearing	Product Name:	Vertical Drilling Machine
Keyword:	CNC Vertical Drilling Milling Tapping Machine	Application:	Metal Processing
Name:	Vertical Automatic Drilling Machine	Machine Type:	Drilling Equipment
Usage:	Metal Drilling Milling	Function:	Drilling Milling Machining
Color:	Customizable	Soindle Travel:	315mm
Max. Drilling Diameter:	50mm	Port:	Qingdao Or Shanghai Port

Products Description

The main performance characteristics：

Mechanical transmission
Mechanical clamping
Mechanical speed
Automatic retraction
Strengthening spindle

Product main technical parameters:

Model	Z3050X16/1
Max.Drilling capacity	50mm
Distance from spindle axis to column (min/max)	350mm-1600mm
Column Diameter	350mm
Spindle taper	MT5
Spindle travel	315mm
Spindle speeds (range)	25-2000
Spindle speeds (number)	16
Spindle feeds (range)	0.04-3.2r/min
Spindle feeds (number)	16
Distance between spindle & working surface of base (min/max)	320mm-1220mm
Worktable dimension	630mm×500mm×500mm
Base dimension	2400mm×1000mm×200mm
Overall dimensions	2500×1060×2650
Spindle motor	5.5HP
G.W / N.W	3600kgs / 3500kgs
Packing dimensions	270cm×112cm×255cm
Applicable Industries	Manufacturing Plant, Machinery Repair Shops, Retail
Marketing Type	New Product 2021
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Warranty of core components	2 years
Core Components	Bearing
Product name	Vertical Drilling Machine
Keyword	CNC Vertical Drilling Milling Tapping Machine
Application	Metal Processing
Name	Vertical Automatic Drilling Machine
Machine type	Drilling Equipment
Usage	Metal Drilling Milling
Function	Drilling Milling Machining
Color	Customizable
Soindle travel	315mm
Max. drilling diameter	50mm

Recommend Products

Company Introduction

Packing&Shipping

FAQ

1. What is the payment Terms ?

A : T/T ,30% initial payment when order ,70% balance payment before shipment ;Irrevocable LC at sight . When we receive the advance payment, we will start to make production.when the machine is ready , we will take pictures to you.after we got your balance payment. we will send the machine to you.

2. What is your trade terms?

A : FOB, CFR and CIF all acceptable.

3.How can I choose the most suitable machines ?

A: Please let us know your machining demand or machine size ,we can choose the best model for you , or you can choose the exact model by yourself. You can also send us the products drawing ,we will choose the most suitable machines for you .

4. What is your trade terms?

A : FOB, CFR,CIF or others terms are all acceptable.

5. What is your minimum order quantity and warranty?

A: MOQ is one set, and warranty is one year.but we will offer lifetime service for machine.

6. What is the package of the machines?

A: The machines standard packed by iron pallets with plastic films
